Bending system with double Double Cylinder on the upper table.
Static and dynamic rigidity provided, strong construction with steel frame and upper table material.
Upper table movement supported by easily adjustable fiber slide bearings.
Durable balancing spindle and eccentric spindle balls that aid parallelism.
Stroke controlled angle adjustment mechanism with mechanical-stop system and motor control.
High stroke and front opening values that facilitate the use of different bending molds.
Hydraulic safety system against excessive pressure rise.
Double speed working system: Free Fall, Bending, Return Back
Multi-function foot pedal with emergency stopconnected to the ESA Controller, normal pressing, stopping at the desired position, automatic table return functions can ball be controlled easily.
Compact, low maintenance REXROTH hydraulic system unit located at the back-top of the machine.
European origin SIEMENS electrical equipment.
Thanks to LEUZE brand forsecurity system, the front barrier bending in different forms with learning mode.
ESA Control Unit
Standard upper tools and Bottom Die
Motorized X and motorized R-axis (OPTION) back gauge with motorized X and motorized R axes that can move at high speed and programmed via ESA control supported with linear guideways: 500 mm back gauge distance and 0.2 mm operating precision, the gauge height is precisely adjusted.
Y AXIS Angle Settingby Motor and ESA Controller
Manual crowning system and Manual adjustable wedges foraligning the top tools.
Quick-release PROMECAM top tool clamping system for partial and quick removing.
Moveable control panel.
Front support arms that can be easily moved with linear slide and bearing systems.
Tightening and fixing bolts to align the bottom die.
Optional Features
Special bending dies.
Special pedal system with two hand and foot control.
